Copper /Copper Alloy Tube Horizontal/ Upward Continous Drawing Casting Production Line

Place of Origin:

Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Brand Name: Jinsheng

1.Being controlled by PLC
2.Having been apllied for Natinal Invent Patent
3.A.C. servo motor

Introduction:

Copper Tube Upward Continues Casting Production Line is a new technology of producing oxygen-free copper tubes with high conductivity and low oxygen content.

This production line is capable of producing directly from cathode copper to bright and long oxygen-free copper tube. The capacity of this system is reneging from 1000 MT to 5000MT.

It consists copper tube winder and the pe-trail uni-drawing line with 5 molds, and has been applied for national invent patent.

Detailed Information about Copper Tube(Burdening)

	Specifications	Annual Output	Casting Strands	Capacity	Running Power	Size
Straight Tube	Φ404~9010	1000MT~3000MT	2~8	80KW~250KW	70KW~200KW	300807
Coiled Tube	281.5~502.5	1000MT~5000MT	2~10	80KW~250KW	70KW~200KW	300807

Advantage:

The weight of single coil is more than 1.5 tons. We can also produce much longer ones. We can provide the Drawing Machine controlled by PLC is capable of producing 2~5 strands and can be adjusted synchronously.

Remarks:

We also provide massive production of copper rods , copper pipe, copper belt, and copper ally products. Welcome your orders.

The Whole Line

The production line includes Drawing Machine, Melting and Holding furnace, Line-separated Rack and Deflector Roll,Crystallizer, Computer Collecting and Arranging Rod System, Collecting Rod Device, and Eclectic System.

Characteristics:

1. Melting and Holding furnace is installed underground which is convenient for feeding raw materials.

2. All the materials can be put into Melting furnace that can simple produce of cutting plates reducing losses.

3. Inductor can be changed rapidly to save time of building furnace.

4, Using abusive high-level refractory material improve the furnace life.

5. Drawing machine and rolling machine are automatically tracked by synchronizer and computer to make speed be feed-backed. In this way, electromechanical integration can be realized.

6. Using rotary flow-ment realizes the measurement and adjustment and control of cool water.

7. But cooling water-pipe uses rapid joint to change crystallizer rapidly and conveniently.

8. Liquid level automatic tracking system guarantees the quality of products.
